+GF+ MIKRON HPM450U

5-AXIS MACHINING CENTERS HPM450U SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION: ONE USED 2013 SWISS +GF+ MIKRON HPM 450U 5-AXIS AUTOMATED MACHINING CENTER: Machine built in Nidau, Switzerland 2012; first installed new June of 2013 -HISTORY- Has machined small high precision aerospace parts Approximately only 9,000 Program run hours over the life of the machine -CONTROL- Heidenhain iTNC 530 with Ethernet and electronic handwheel for part setup -WORKING RANGE- -ROTARY TILTING TORQUE MOTOR TABLE- Pallet Version    System 3R Dynafix 280 mm x 280 mm (11.02" x 11.02") Pallets Maximum Weight On Table    150 kg (331 lbs) manual; 90 kg (198 lbs) automatic Automatic Pallet Changer    7 Pallets capacity(No pallets come with machine) Max pallet size possible for this machine    350 mm x 350 mm (13.8" x 13.8") -FEED DRIVES- -STEPTEC SWISS MADE SPINDLE- -120 POSITION TOOL CHANGER TOWER- -EQUIPPED WITH- Complete machine enclosure Pallet changer Dynafix 280x280 Spindle chiller Direct measuring system Heidenhain glass scales X/Y/Z, Encoders B,C 60 position tool changer 18-70 bar (261 PSI-1,015 PSI) Coolant Thru The Spindle Paper band micro filter system 650 liter (172 gallon) capacity tank BLUM laser tool measuring of tool length and diameter M&H Infrared Parts Measuring Touch Probe Lift-up Chip Conveyor Spray Gun Beacon Blow-off unit for laser measuring system All feed motors are liquid-cooled
