DMG MORI DECKEL MAHO DMU 40 monoBLOCK

5-AXIS MACHINING CENTERS DECKEL MAHO DMU 40 monoBLOCK SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION: Used 2010 DECKEL MAHO DMG-DMU 40monoBLOCK Full 5-Axis Machining Center: -HISTORY- Used 825 hours in an artist's studio to mill aluminum & copper sculptures Made in Pfronten, Germany, this is a Full 5-Axis Simultaneous machine Heidenhain iTNC530 CNC control with 15" TFT screen & Electronic Handwheel -WORKING RANGE- -FEED DRIVES- -TOOL MAGAZINE- -HEIDENHAIN GLASS SCALES X/Y/Z AXES DIRECT PATH MEASURING SYSTEM- -HEIDENHAIN ROTARY ENCODERS B/C AXES DIRECT PATH MEASURING SYSTEM- -EQUIPPED WITH- Fully enclosed protection cabin NC Rotary Table (C-axis) full 4th axis 18,000 RPM Motor Spindle with Active Cooling NC-Controlled Swivel Milling Head (B-Axis) 5th Axis with Active Cooling Swivel Range 125 Degrees(0 is Vertical/-90 is Horizontal) +30/-95 Degrees Rapid traverse of the B-Axis is 35 rpm, swivelling time approx. 1.5 sec 158 gallon (600 liter) high pressure coolant tank with paper band filter 580 PSI (40 bar) coolant thru the spindle centre Chip conveyor External flood coolant on outside of spindle 14.5 PSI (1 bar) pressure, 10.6 gallon/min (40 l/min) flow rate Infrared parts measuring touch probe BLUM Laser tool measuring-tool length & diameter & broken tool detection NFS-Server software Cooling by air blast Spray pistol with pump Signal lamp with 4 colors 3D quickSET machine kinematics calibration kit
